EH 1003,1004 Series | Low Pressure Brass Ball Valve (Brass)
One-way check valve for in-line use. Suitable for any type of hydraulic system using liquid that is not highly viscous. The standard type is in zinc-plated carbon steel, and it is suitable for non-corrosive mineral-based oils and liquids.
Call Tawk.to
contact@ehhydraulics.com
EH 1003,1004 Series | Low Pressure Brass Ball Valve (Brass)
One-way check valve for in-line use. Suitable for any type of hydraulic system using liquid that is not highly viscous. The standard type is in zinc-plated carbon steel, and it is suitable for non-corrosive mineral-based oils and liquids.
Call Tawk.to
contact@ehhydraulics.com
Dimensions
| Other Threads/Fitting Ends Are Available Upon Request | |||||
| Body Size(Inch) | A(mm) | B(mm) | C(mm) | D(mm) | E(mm) |
| 1/4” | 41.8 | 8 | 21.5 | 53.5 | 36.5 |
| 3/8” | 45 | 10 | 25 | 53.5 | 37 |
| 1/2” | 53 | 14 | 29 | 53.5 | 39 |
| 3/4” | 60.7 | 19 | 35.5 | 53.5 | 41.5 |
| 1” | 69 | 23 | 42 | 62 | 50 |
| Other Threads/Fitting Ends Are Available Upon Request | |||||
| Body Size(Inch) | A(mm) | B(mm) | C(mm) | D(mm) | E(mm) |
| 1/4” | 52 | 8 | 21.5 | 53.5 | 36.5 |
| 3/8” | 55 | 10 | 25 | 53.5 | 37 |
| 1/2” | 59 | 14 | 29 | 53.5 | 39 |
| 3/4” | 68.2 | 19 | 35.5 | 53.5 | 41.5 |
| 1” | 76.2 | 23 | 42 | 62 | 50 |
Technical specifications
| Dash Size | Body Size (Inch) | Max. Work Pressure(bar) |
| 04 | 1/4” | 25 |
| 06 | 3/8” | 25 |
| 08 | 1/2” | 25 |
| 12 | 3/4” | 25 |
| 16 | 1” | 25 |
| Material: | Brass | |
| Seals: | NBR, Seals can be customized to meet your special work condition/media | |
| Working Temperatures: | -25 °C to 125 °C, Customizable | |
| Surface Treatment: | / | |
| Specifications: | Product Interchange | / |
| Valve Type: | Ball | |
| Connection: | Handle | |
| Disconnection: | Handle | |
| Connection Under Pressure: | Not Allowed | |
